صمام تحكم من الفولاذ المقاوم للصدأ - 2 اتجاه

سعر: $131.6~$2096

Diameter: DN15 – DN250

Valve body: Precision casting 304 stainless steel

Valve stem, valve core and valve seat: 304 stainless steel

الضغط: PN16

Temperature: 0~350℃

Leakage rate: Kvs≤0.02%

Stroke: DN40 – DN100 20mm,DN125 – DN350 40mm

Suitable for connection control in district heating systems and HVAC systems requiring fluids with excellent dynamic stability, low noise, and minimal leakage.

Maximum Allowable Differential Pressure: 1000 kPa / 1600 kPa
Connection Standard: Complies with GB9113 flange connection standard
Valve Body Adjustment Method: Pressure-balanced design ensures high shut-off capability with low operating force
Stem Seal: Composite special-purpose seal
Holds Special Equipment Manufacturing License for Pressure Pipeline Components
