Manual flow control slows projects and causes errors. Agitate— wasted energy, leaks, and call-outs stack up fast. Solution— an electric ball valve with the right actuator gives precise, safe, and fast control for HVAC and plant systems—without babysitting.
An electric ball valve is a quarter-turn ball valve that you actuate with an electric actuator. It uses an electric motor to rotate the ball, opening or closing flow with high reliability, tight seal, and simple wiring for remote operation and automation—ideal for HVAC and industrial applications requiring precise flow control.
stainless steel electric ball valve
An electric ball valve is a ball valve whose stem is mounted to the actuator instead of a handle. Inside, a drilled ball sits in the valve body. When the actuator turns the stem a quarter turn, the passage aligns or blocks the pipeline to control the flow of a liquid or gas. The design is simple and durable.
These valves are fast to install and easy to wire. Because the actuator’s gearbox multiplies torque, even sticky services shut tight. Most valves are designed with a full port option for minimal pressure drop and a weatherproof housing for harsh sites. Explore a stainless steel electric ball valve with a direct mount ISO 5211 mounting pad for easy integration in control panels via our electric ball valve product page. Stainless steel electric ball valve with direct mount ISO 5211 pad.
Electric actuation shines when you want simple wiring, local control, and steady positioning. You can drive a motorized ball valve from a BMS, DDC, or PLC with on/off or analog signals. It’s quiet, clean, and supports automatic sequencing.
Pneumatic systems excel where air is already available, where fast-acting moves or ATEX safety are key. For many plants, the best answer is mixed: keep dampers automated with pneumatic or electric as needed, and automate small utility lines with compact electric actuated packages. If you’re comparing options, see our smart flow meter valve integrated device for plug-and-play monitoring and control in one skid: integrated smart flow meter valve device.
Right-sizing starts with process psi, media, and temperature. Add safety margins for sticky media and aging seats. Actuator torque must beat the worst-case breakaway, then allow for long service life. For low pressure and clean water, a full port reduces loss.
Table — quick sizing cues (illustrative):
| Valve Size (in) | Typical ΔP (psi) | Suggested Actuator Output (N·m) | Port Type | Notes |
| 1/2 | 50 | 10 | Full | Great for coil bypass |
| 1 | 80 | 25 | Full | Add feedback limit switches |
| 2 | 100 | 60 | Full | Verify mounting pad per ISO 5211 |
| 3 | 120 | 120 | Full | Consider gear ratios for sticky media |
When in doubt, check manufacturer data sheets (e.g., Valves from Valworx publish easy charts) and request engineering support from the factory. For HVAC branches, our motorized ball valve range covers typical coil loads: motorized ball valve for HVAC zones.
Torque vs. Valve Size (illustrative)
1/2″ |■■■■■■■■ 10 N·m
1″ |■■■■■■■■■■■■■■ 25 N·m
2″ |■■■■■■■■■■■■■■■■■■■■■■ 60 N·m
3″ |■■■■■■■■■■■■■■■■■■■■■■■■■■■■■■■■ 120 N·m
Yes. Many packages take 110 or 110v AC (and 24 V options), with simple spade terminals. An electric actuator will use an electric motor and gears to turn the stem. Typical on/off models include internal cams striking limit switches to stop power at end of travel; analog units modulate to position.
For building controls, use direct mount actuators with clear labels and end-of-travel lights. Need plastic wetted parts and mains power? Consider our UPVC electric ball valve—safe for corrosive water and easy to wire: UPVC electric ball valve option.
Even simple on/off valves benefit from limit switches for PLC confirmation. Analog valves add 4–20 mA or 0–10 V input and position feedback for automation trends. With feedback, you can verify that the valves are used correctly and diagnose sticking before it becomes downtime.
Our controls lineup includes a compact electric actuator for tight spaces and network-ready drives. If you need digital networking, explore RS485 rotary actuator for BMS integration or proportional rotary actuator for fine control and remote operation from a central SCADA: RS485 rotary actuator and proportional rotary actuator.
Stainless steel gives top corrosion resistance and strength; choose it for steam, chemicals, or seawater. Where budget and potable rules allow, brass can be fine. For non-metallic lines, PVC is light and clean. Seat and seal choices (PTFE, reinforced) complete the picture.
For harsher media, a stainless steel ball inside stainless steel ball valves keeps wear low. Where sanitation matters, machined bores and polished seats add reliability. For rugged industrial duty, review our stainless steel electric actuated builds here: stainless steel electric ball valve series.
Pick the end type that matches your piping: flange for larger lines and easy removal, thread for small retrofits, and socket for glued plastic systems. Always check the valve mounting interface and mounting pad size so the actuator fits.
Most industrial packages follow ISO 5211 square drive patterns, so actuators mount in minutes. Our direct mount stainless series keeps the actuator integral to the valve, cutting brackets and slop, while network options keep you remotely aware of status. See the plastic electric butterfly valve companion for big flows: electric butterfly valve (uPVC).
Two-way handles open/close needs. 3-way designs mix or divert—perfect for coils and heat recovery loops. An electrically actuated ball offers smooth flow control and tight shutoff. Choose normally closed or normally open spring return logic when the process demands a fail position.
For smarter buildings, our networked electric valves pair with M-Bus, LoRaWAN, or Zigbee for portfolio-level visibility. See these smart options: M-Bus smart valve and Zigbee smart water valve.
On install day, verify the ISO 5211 pattern, fastener lengths, and stem flats. A direct mount keeps alignment true. Confirm rotation direction, perform a dry run, and record stroke time. Label the voltage, I/O, and enclosure rating on the box for maintenance crews.
Commissioning tips for HVAC:
For water balancing and networked room control, consider a smart electric control valve companion device: smart flow meter valve integrated device.
A food plant had aging manual valves on CIP loops. Operators walked long aisles to open and close lines, risking burns and errors. We replaced them with electric actuated stainless packages, automatic ball valves configured as normally closed, tied to recipes with automatic sequencing.
The result? Faster changeovers, fewer mix-ups, stronger plant safety, and energy savings. Networking let maintenance see status efficiently and plan downtime remotely. For similar upgrades, our team can help pick the right actuator, pick weatherproof enclosures, and size drives for your applications requiring precise shutoff. See our stainless series and companion actuators: stainless electric ball valve and RS485 rotary actuator.
How do I choose between electric and pneumatic actuators?
If you want simple wiring and digital control, choose electric. If you already have plant air or need ultra-fast-acting moves, go pneumatic. Many sites blend both with pneumatic or electric actuators depending on duty.
Can I buy ball valves online today?
Yes—many factories and distributors offer ball valves online today. Always confirm data sheets and configuration (size, port, end type, and signal) before checkout.
What enclosure should I select for washdown areas?
Pick a weatherproof actuator with stainless hardware and sealed entries. For chemicals or steam, prefer stainless steel wetted parts and reinforced seats.
Do electric valves fail safe?
Yes. You can specify normally open or normally closed with failsafe spring or battery. This protects plant safety if power drops.
What signals are common for building controls?
On/off uses 2-wire or 3-wire; modulating uses 0–10 V or 4–20 mA. Always match voltage and I/O to the controller, and verify limit switches or feedback when commissioning.
What’s the difference between on/off and modulating packages?
On/off opens or closes. Modulating tracks an analog signal to position the ball. Many actuators include integral control cards for smooth motion and long life.
As a factory team, we build high-quality packages on short cycles and support custom firmware, signals, and materials. Our lines cover electric on/off and modulating valves, plus balancing, butterfly, and smart networking options. That means you get one partner for sizing, selection, and field help.
If you need an actuated ball valve tailored to an OEM skid, we’ll assemble it, test it, and ship it ready to bolt in. We also stock proportional and digital actuators for retrofits. For plastics, see the UPVC electric ball valve and electric butterfly valve pages for low-weight options (uPVC electric ball valve and uPVC electric butterfly valve).
